Posted in: Specs | by Brian Taylor | 2019 Jan 03
FT232RL Adapter
FT232 Module CP2102 Serial Port USB to TTL FT232RQ MICRO Interface Module Converter Baord Compatible with FT232RL

1. CJMCU-CP2102 has a high degree of integration, built-in USB2.0 full-speed functional controller, USB transceiver, crystal oscillator, EEPROM and asynchronous serial data bus (UART), support modem full-functional signals, without any external USB devices.
Origin: Hong Kong
Delivery: 01-23, 03-06
datepaid: 2018-12-25
Received: 2019-01-14
Quantity: 1pcs
Price: 2.89
Shipping: 0.00
Total: 2.89
2. CJMCU-CP2102 works similarly with other USB-UART switching circuits. The USB port of PC is virtualized as a COM port by the driver to achieve the purpose of expansion.
3. CJMCU-attitude module communication, USB to TTL module, 5V power output, TTL level CP2102 kernel CJMCU-CP2102 is a highly integrated USB-UART bridge, can provide a minimal components and PCB space to achieve RS232 conversion USB simple solution.
4. Users can transform the USB interface to the RS232 interface by using CJMCU-CP2102.

1. 2102 chip, after installing driver, generate COM port.
2. Connect the standard MICRO MINI-USB wire input to the computer USB interface, with 3.3V and 5V voltage two kinds of power output.
3. On-board status indicator, transceiver indicator, properly installed and driven status indicator will always be on, transceiver indicator will flicker when communicating, with running LED indicator.
4. Support baud rate from 300bps~1Mbps.
5. Communication format support: A. 5,6,7,8 bit data; B. 1,1.5,2 stop bit support; C. odd, even, mark, space, none check.
6. Support operating system: Windows 8.1/7/vista/xp/98, for Mac OS-X/OS-9, Linux.
7. The USB seat interface is MICRO MINI-USB.
8. The patch elements are welded by regular companies, with stable quality and beautiful appearance.
9. With DTR trigger signal output, can be directly to Pro Mini ATMEGA328P and other motherboard download program communication.

Module size: 20mm x 16mm x 4mm/0.78x0.62x0.15''
Packing weight: 3g

Please allow 1-3mm differs due to manual measurement.
Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.

Package Included: 1 x FT232 Module
